使用Alexnet進行遷移學習（MATLAB）
前言：
? ? ? ?本文基于預訓練的卷積神經網絡（Convolutional Neural Network，CNN）進行模型創建,進行調整后應用到已有的數據集電熔鎂砂（Fused magnesium furnace, FMF）工況識別（實驗室數據集，不公開）。
正文：
? ? ? 這里不對數據集背景展開介紹，為了方便說明，視FMF數據集為一個故障識別問題，故障工況的標簽為1，非故障工況的標簽為0。FMF數據集樣本來自于實際電熔鎂爐同一批爐次工況運行的片段，后期經過圖像增強處理，圖像大小為32X32X3的RGB圖像。其中使用訓練集traindata2.mat包含3010張圖像，故障數與非故障數比例為1923：1087；使用測試集testdata4.mat包含626張圖像，故障數與非故障數比例為416：210。
實驗環境使用MATLAB 2022b的深度學習工具箱以及附加功能資源。
建議先安裝好附加資源管理器的AlexNet
修改全連接層
非常失敗的一次嘗試，為了適應Alexnet網絡輸入，調整圖片輸入為227*227*3，訓練結果只有91%的準確率，在測試集上效果不理想
%% Alexnet遷移學習
%% 清空環境和圖窗
clear
close all
%% 導入模型
net = alexnet;
layers = net.Layers
layers(end-2) = fullyConnectedLayer(2); ?%故障識別為二分類
layers(end) = classificationLayer;
%% 準備數據集
load("traindata2.mat")
len = length(label);
img(:,:,:,len) = zeros(227,227,3); %預分配內存
for i ?= 1:len
? ?img(:,:,:,i) = imresize(video(:,:,:,i),[227 227]); %調整輸入大小為227*227*3
end
rng(10) ? % 設置seed，便于復現
randIndex = randperm(len);
len1 = round(0.7*len);
trainIndex = randIndex(1:len1);
testIndex = randIndex(len1+1:end);
trainlabels = label(trainIndex);
trainImages = img(:,:,:,trainIndex);
vallabels = label(testIndex);
valImages = img(:,:,:,testIndex);
trainlabels = categorical(trainlabels);
vallabels = categorical(vallabels);
%% 模型訓練
options = trainingOptions('adam',...
? ?'ExecutionEnvironment','gpu',...
? ?'InitialLearnRate',0.01,...
? ?'MiniBatchSize',128,...
? ?'MaxEpochs',100,...
? ?'Shuffle','every-epoch',...
? ?'ValidationData',{valImages,vallabels},...
? ?'ValidationFrequency',50,...
? ?'Verbose',false,...
? ?'Plots','training-progress');
net = trainNetwork(trainImages,trainlabels,layers,options);
%% 測試集驗證
load('testdata4_label.mat')
testlabels = categorical(label);
len1 = length(testlabels);
img1(:,:,:,len1) = zeros(227,227,3);
for i = 1:len1
? ?img1(:,:,:,i) = imresize(video(:,:,:,i),[227 227]);
end
pred_labels = classify(net,img1);
test_Acc = sum(pred_labels == testlabels')/len1
cm = confusionchart(testlabels',pred_labels); %推薦使用
cm.ColumnSummary = 'column-normalized';
cm.RowSummary = 'row-normalized';
cm.Title = 'SAPI-FMF Confusion Matrix';
對比實驗，使用自定義的CNN，網絡結構更簡單，不對原始輸入進行調整
%% 清空變量和圖窗
clear;
close all;
%% 導入數據集
load("traindata2.mat")
len = length(label); ?
rng(10) ? % 設置seed，便于復現
randIndex = randperm(len);
len1 = round(0.7*len);
trainIndex = randIndex(1:len1);
testIndex = randIndex(len1+1:end);
trainlabels = label(trainIndex);
trainImages = video(:,:,:,trainIndex);
vallabels = label(testIndex);
valImages = video(:,:,:,testIndex);
trainlabels = categorical(trainlabels);
vallabels = categorical(vallabels);
%% 定義神經網絡
layers = [
? ? imageInputLayer([32,32,3])
? ? convolution2dLayer(5,32,'Padding','same')
? ? maxPooling2dLayer(2,"Stride",2,"Padding","same")
? ? dropoutLayer(0.3)
? ? convolution2dLayer(3,32)
? ? batchNormalizationLayer
? ? reluLayer
? ? maxPooling2dLayer(2,'Stride',2)
? ? fullyConnectedLayer(2)
? ? softmaxLayer
? ? classificationLayer
];
options = trainingOptions('adam',...
? ?'ExecutionEnvironment','multi-gpu',...
? ?'InitialLearnRate',0.01,...
? ?'MiniBatchSize',128,...
? ?'MaxEpochs',100,...
? ?'Shuffle','every-epoch',...
? ?'ValidationData',{valImages,vallabels},...
? ?'ValidationFrequency',50,...
? ?'Verbose',false,...
? ?'Plots','training-progress');
net = trainNetwork(trainImages,trainlabels,layers,options);
%% 測試集驗證
load('testdata4_label.mat')
testlabels = categorical(label);
testImages = video;
len2 = length(testlabels);
pred_labels = classify(net,testImages);
test_Acc = sum(pred_labels == testlabels')/len2
cm = confusionchart(testlabels',pred_labels); %推薦使用
cm.ColumnSummary = 'column-normalized';
cm.RowSummary = 'row-normalized';
cm.Title = 'SAPI-FMF Confusion Matrix';
cm.RowSummary = 'row-normalized';
cm.Title = 'SAPI-FMF Confusion Matrix';
? 針對二維卷積神經網絡的模型，訓練效果均不太理想，同時由于所選數據集分布不合理，訓練的模型傾向于無故障的分類（實際的數據集比所選數據集要多），模型準確性和泛化能力更差；另一方面，模型參數和優化參數沒有充分調整。本文借助于MATLAB進行初步的驗證和嘗試，后面會使用基于python的深度學習框架pytorch或者Tensorflow進行模型的搭建和訓練。
